Technical Data
Operating voltage 24 V DC (18...30 V DC)
Current adjustment 1 A, 2 A, 3 A, 4 A, by countersinked rotary switch, sealed
Inrush capacity max. 20 mF (per channel)
Group alarm output potential free alarm output 30 V AC/DC, 100 mA
Remote start (ON) 10...30 V DC
Impulse length min. 20 ms
General data
Connection Spring clamp terminals
Input terminals 2 × 16 mm²
Output terminals per output 1 × 4 mm²
Alarm terminals 2.5 mm²
Bridging concept two sides, with spring clamp terminals or bridge set (max. 40 A)
Mounting method DIN-rail mountable TH35 (EN 60715)
Temperature range 0...+55 °C (storage temperature -40...+80 °C)
Commercial data
Net weight 160
Weight unit Gram
Basic unit pc.
Customs tariff number 85363010
Unit (piece) 1
Minimum order quantity (piece) 1
Functions
Adjustable current range
Intelligent current monitoring
Signal contact
