Technical Data
Operating voltage max. 250 V AC/DC
Operating current per contact max. 9 A
Connection cross section max. 1.5 mm²
Sealing range (cable diameter) 6...8 mm
Locking of ports Screw thread 7/8" (recommended torque 1.5 Nm) self-securing
Protection IP65 and IP67 when plugged and screwed down (EN 60529)
Temperature range -25...+85 °C
Commercial data
Net weight 10
Weight unit Gram
Basic unit pc.
Customs tariff number 85369010
Unit (piece) 1
Minimum order quantity (piece) 1
