Technical Data
Operating voltage max. 250 V AC/DC
Operating current per contact max. 9 A
Connection cross section max. 1.5 mm²
Sealing range (cable diameter) 10...12 mm
Locking of ports Screw thread 7/8" (recommended torque 1.5 Nm) self-securing
Protection IP65 and IP67 when plugged and screwed down (EN 60529)
Temperature range -25...+85 °C
