Form
18007
Technical Data
Operating voltage 24 V AC/DC ±25 %
Operating current per contact max. 4 A
Locking of ports M3 (recommended torque 0.4 Nm)
Protection IP67 inserted and tightened (EN 60529)
Temperature range -25...+85 °C, depending on cable quality
Cable
No./diameter of wires 3 × 0.75 mm²
Wire isolation PVC (bk, num, gnye)
C-track properties 2 million
Jacket PUR/PVC
Outer diameter approx. 5.9 mm
Bend radius (moving) 15 × outer diameter
Temperature range (fixed) -30...+80 °C
Temperature range (mobile) -5...+80 °C
Commercial data
Net weight 186
Weight unit Gram
Basic unit pc.
Customs tariff number 85444290
Unit (piece) 1
Minimum order quantity (piece) 1
