Technical Data
Operating voltage max. 60 V AC/DC
Operating current per contact max. 4 A
Connection cross section max. 0.75 mm²
Sealing range (cable diameter) 6...8 mm
Protection IP65 and IP67 when plugged and screwed down (EN 60529)
Housing CuZn, nickel plated
Temperature range -25...+85 °C
