Features
(green)
24 V AC/DC
Protection IP40

Technical Data
Operating voltage 24 V AC/DC ±15 %
Current consumption 15 ±2 mA
Protection acc. to (IEC 60529/EN 60529) IP40
General data
Housing Adapter – PVC, gray
Front panel hole diameter Ø 8 mm
LED Ø 5 mm
Temperature range -40...+70 °C
Dimensions H × W × D 18.5 x 12 x 53 mm
Connection Faston 2.8 × 0.8 mm
