Input
Input voltage 3 × 208...520 V AC
Frequency 50...60 Hz
Output
Output voltage 24 V DC (SELV)
Output current max. 15 A
Ripple max. 2 % rms
Output fuse (external) 15 A (T)
Output filter LED, VDR and smoothing capacitor
General data
Standards (EN 61558-2-6), (EN 62041 category I), (EN 55011 B), (EN 61000-3-2)
Temperature range -20...+55 °C, for any mounting position at vertical wall, no condensation
Mounting method Key-hole mounting
Efficiency 75 %
Dimensions H × W × D 220 x 82 x 208 mm
Fixing centers a × b × c 195 x 60 x 8 mm
